Home > Cut-off Machine > Wire Rope Cutting Machine > Large Square Pneumatic Cable Cutting Machine WPM-5-150MM2
Large square Pneumatic cable cutting machine WPM-5-150MM2
Large square Pneumatic cable cutting machine WPM-5-150MM2
  • Large square Pneumatic cable cutting machine WPM-5-150MM2

  • Model No: WPM-5-150MM2

  • Large square Pneumatic cable cutting machine WPM-5-150MM2, Big Cable Cutting Machine, New Energy Car Cable Cutting Machine, Wire Cut Off Machine
    ♣ Simple operation and fast speed, minimal gas consumption, low failure rate, easy maintenance
    ♣ This product is a non-standard machine, specialized in cutting large cables, it adopts power type and pneumatic pedal type to achieve the cutting effect.
    ♣ The tangent line is made of a powerful cylinder with a bore of 100, a stroke of 50, and a three-dimensional shape.
    ♣ Cut for large cables.
    ♣ Minimal gas consumption, low failure rate, and easy maintenance.
    ♠ Suitable for 5-150 square large electronic wires, cables, power cables, USB cables, coaxial cables, BV wires, etc.
    ♣ We can customize suitable machines for different wire ranges according to customer needs.

  • Inquiry now
Detailed description
Large square Pneumatic cable cutting machine WPM-5-150MM2, Big Cable Cutting Machine, New Energy Car Cable Cutting Machine, Wire Cut Off Machine


♣ Simple operation and fast speed, minimal gas consumption, low failure rate, easy maintenance
♣ This product is a non-standard machine, specialized in cutting large cables, it adopts power type and pneumatic pedal type to achieve the cutting effect.
♣ The tangent line is made of a powerful cylinder with a bore of 100, a stroke of 50, and a three-dimensional shape.
♣ Cut for large cables.
♣ Minimal gas consumption, low failure rate, and easy maintenance.
 ♠ Suitable for 5-150 square large electronic wires, cables, power cables, USB cables, coaxial cables, BV wires, etc.
♣ We can customize suitable machines for different wire ranges according to customer needs.
&
Name Pneumatic large cable cutting machine
Air Pressure 0.4-0.7Mpa
Power 220V 50-60HZ
Weight 35kg
Cutting Length 1-99999.99mm
Size 400*450*200
Stroke 50
Cylinder Bore φ100
Wire Range 5-150mm2 BVR Wire(Can Customize)

Large square Pneumatic cable cutting machine, Big Cable Cutting Machine, New Energy Car Cable Cutting MachineBig Cable Cutting Machine, New Energy Car Cable Cutting Machine, Wire Cut Off Machine Big Cable Cutting Machine, New Energy Car Cable Cutting Machine, Wire Cut Off Machine Sample display of Big Cable Cutting Machine, New Energy Car Cable Cutting Machine, Wire Cut Off Machine
